WHYTE TOURUS GRAVEL BIKE
WHYTE TOURUS GRAVEL BIKE
Couldn't load pickup availability
COLLECTION OIN STORE ONLY
Commute, ride or explore
Tourus is our light gravel, all-road commuting, touring and utility bike. Playful and practical, it offers an outstanding blend of value, versatility, and performance everywhere. Whether mixing up the roads with the rough, heading out for a bike packing adventure, or getting to work and back swiftly and efficiently.
Highlights
– Fully featured, multi-butted 6061 T6 hydroformed frame.
– Straight bladed 6061 alloy fork with mounting points.
– 2x10 Shimano GRX transmission (46-30T x 11-34T).
– Shimano GRX hydraulic disc brakes (180mm rotor front, 160mm rear).
– High-volume Maxxis 700x45mm tyres on tubeless-ready rims.
Specifications
| COLOUR | Gloss black and silver | CASSETTE | Shimano CS-HG500, 11-34T, 10 speed |
|---|---|---|---|
| FRAME | 6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts | CHAIN | Shimano CN-HG54 |
| FORK | Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, flat mount with mudguard and mounting bosses | CRANKSET | Shimano FC-RX600, 170mm length (size XS and S), 172.5mm (size M, L and XL), 46-30T chainring |
| REAR SHOCK | N/A | BOTTOM BRACKET | Shimano SM-BB52, 68/73mm |
| HEADSET | No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed cartridge bearings and front entry for cables | SEATPOST | Whyte 6061 Alloy, 20mm offset, 27.2mm x 350mm, two-bolt clamp |
| REAR HUB | Alloy, Double Sealed Cartridge Bearings, 12mm x 142mm Thru Axle, Centre-Lock, 32 Hole | SADDLE | Whyte Custom |
| FRONT HUB | Alloy, double sealed cartridge bearings, 12mm x 142mm thru axle, Center-Lock, 32 hole | HANDLEBAR | Whyte, 6061 alloy, 70mm reach, 120mm drop, 10° flare 31.8mm x 400mm (sizes XS + S), 420mm (size M), 440mm (size L), 460mm (size XL) |
| SPOKES | 2.0mm, PG, black stainless, brass nipples | STEM | Whyte Alloy, +-7° rise, 60mm length (size XS + S), 70mm (sizes M, L, + XL) |
| RIMS | 23mm internal width, tubeless ready, 32 hole | GRIPS | Whyte anti-slip, ‘cross bar tape |
| TYRE | Maxxis Reaver Tanwall 700 x 45c, EXO wire bead | BRAKES FRONT | Shimano GRX BR-RX400, Flat Mount, internal routing, 180mm rotor |
| SHIFT LEVERS | Shimano GRX ST-RX400, 10 Speed | BRAKES REAR | Shimano GRX BR-RX400, Flat Mount, internal routing, 160mm rotor |
| FRONT MECH | Shimano GRX RD-RX400, 10 Speed | BRAKE LEVERS | Shimano GRX ST-RX600, hydraulic |
| REAR MECH | Shimano GRX RD-RX400, Shadow Plus, 10 Speed | PEDALS | Fibre reinforced composite platform |
| WEIGHT | TBC |
Although we've taken every effort to ensure the accuracy of the information listed here sometimes things change so we reserve the right to change or update bike specifications, features, prices and colours as and when required.
Geometry
| FRAME SIZE | Extra Small | Small | Medium | Large | Extra Large |
| A - REACH (mm) | 398.5 | 413.5 | 428.5 | 436 | 448.5 |
| B - STACK (mm) | 563 | 577.3 | 591.4 | 605.4 | 619.5 |
| C - HEAD ANGLE (° degrees) | 70 | 70 | 70 | 70 | 70 |
| D - SEAT ANGLE (° degrees) | 74.5 | 74.5 | 74.5 | 74.5 | 74.5 |
| E - BB HEIGHT (mm) | 283.5 | 283.5 | 283.5 | 283.5 | 283.5 |
| F - WHEELBASE (mm) | 1052 | 1072 | 1092 | 1105 | 1123 |
| G - REAR CENTRE (mm) | 445 | 445 | 445 | 445 | 445 |
| H - STANDOVER HEIGHT (mm) | 727 | 745 | 766 | 788 | 814 |
| I - SEAT TUBE LENGTH (mm) | 405 | 430 | 460 | 490 | 530 |
| J - HEAD TUBE LENGTH (mm) | 123 | 138 | 153 | 168 | 183 |
